Beyond a Single Card: How Giant Language Models Run on Hundreds of GPUs

The largest AI models today carry over a trillion parameters, needing close to 2 terabytes of memory just to store their weights. Yet the biggest GPU on the market offers about 288 GB — nowhere near enough for these frontier giants. So how do the chatbots used by millions of people every day serve these models reliably? The answer is disarmingly simple: there is no single mega-computer hosting them. They run on a coordinated system of dozens, sometimes hundreds, of GPUs. On the IBM Technology channel, Grace Ableidinger opens up how an LLM inference workload stays alive at that scale, step by step.

Serving a model in production means solving three constraints at once. First, the model memory footprint: every weight must sit in memory before work begins. Second, the working memory known as the KV cache : as the model generates its reply it keeps the conversation context there, and the area grows with every token produced. Third, request throughput: when hundreds or thousands of people hit the model at once, each request queues on the card and everyone's wait grows as the line lengthens. The KV cache is the sneakiest of the three because it never sits still — it swells for as long as generation continues. According to Nvidia's Dynamo work, that swelling context can move off GPU memory into cheaper tiers such as CPU memory and fast disks; validations with Vast and WEKA measured 35 GB/s into a single H100 and 270 GB/s across eight cards.

Meet traffic first: data parallelism

When the model and its cache fit on one card but the user count grows out of control, the simplest fix is copying the whole model onto multiple cards. In data parallelism , each card holds an identical replica and incoming requests route by current load — even by which card already holds the relevant context in its cache. The replicas need no coordination; the job is simply admitting each request through the right door. Per the vLLM team's distributed-inference post of February 17, 2025, low-bit quantization alone stops being enough past hundreds of billions of parameters, which is why the engine offers tensor parallelism inside a card and pipeline parallelism across cards. Traffic, then, is solved with replica counts; fit is solved with splitting techniques.

Copying stops working for truly huge models because the model itself will not fit on one card. A model is really a sequence of transformer layers holding knowledge, and inference means pushing the input through them one after another. Pipeline parallelism cuts the model into layer groups: early layers live on the first card, later ones on the second. Send a single request and most cards idle while waiting their turn, so requests stream through continuously like an assembly line, keeping every station busy. Baseten's engineering notes put a billion parameters at roughly a gigabyte of memory in FP8 precision; the 671-billion-parameter DeepSeek-V3.1 throws an out-of-memory error on a single B200, and even 720 GB across four B200s covers the weights while leaving no room for the KV cache — which usually claims 80 percent or more of whatever space remains after weights. The result: real traffic at this scale wants a full eight-card node.

Two ways to split a model: pipeline and tensor

Instead of cutting the model vertically, it can be cut horizontally. Tensor parallelism splits the math inside each layer rather than the layers themselves: every card takes a slice of the same layer, computes its share, then the cards combine partial results. That combining step is a collective operation, a blocking barrier at every layer — the cards must chatter constantly mid-computation. Such dense conversation only works over a high-bandwidth, low-latency link inside one server; over a slow network the chatter becomes the bottleneck instead of the optimization. DigitalOcean's guide notes a dense 70-billion-parameter model in BF16 needs about 140 GB for weights alone; a model comfortable at 4K context may refuse to fit at 64K or 128K under realistic production traffic. The message is plain: the speed of the road between cards matters as much as the splitting technique.

Then there is the model family that works like a community of specialists: mixture of experts. Instead of running one weight block for every input, these models hold small sub-networks tuned to different sides of generation — one leaning toward code samples, another toward punctuation, a third toward numbers. Expert parallelism spreads those experts across cards so no card holds the entire model. At every layer a router dispatches each token to the handful of experts it picked; current models select about 8 out of 256, and the outputs merge afterward. Compute per token drops sharply, paid for in heavy cross-card dispatch traffic. As Modular's handbook stresses, each data-parallel replica may itself use tensor or pipeline techniques internally, and the router draws a failure boundary by retiring replicas that miss their health checks.

Pool hardware by job type: prefill and decode

The two phases of LLM inference stress hardware in completely different ways. In prefill , the model reads and digests the input, running dense parallel math over fixed weights at compute speed while building the KV cache. In decode , the reply emerges token by token, pulling the whole grown cache out of memory each step at memory-bandwidth speed. Park both phases in one pool and decode's swelling appetite squeezes prefill's territory. The fix moves each phase onto its own GPU pool tuned to its bottleneck — but only pays off if the cache flies between pools almost instantly. Plain TCP over standard Ethernet cannot keep up; the link must be dedicated, low-latency, RDMA-capable fabric. Amazon's SageMaker HyperPod account connects the split pools with EFA and RDMA, tunes time to first token and inter-token latency independently, and keeps long inputs from stalling live generation. Ray's guide adds that the same split scales each phase independently on cheaper, heterogeneous node types, with vLLM's NIXL and LMCache transfer backends carrying the load.

Production systems stack the methods: tensor splits confined to one machine, pipeline stages spanning machines, data replicas absorbing traffic, experts sharded for mixture models, plus pools divided by serving phase. That stacking is called multi-dimensional parallelism. Above everything runs a coordination tier that sends each request to its proper GPU pool, evens out load, and absorbs failed cards without dropping requests. As the presenter sums up, the rule is plain: traffic overflowing, add replicas; model not fitting, split it layer by layer or slice by slice; memory swelling from two different jobs, give each job its own pool. Distributed inference is not stubbornness about cramming giant models into one machine — it is the discipline of cutting work into the right pieces and running each on the right hardware.
